Flux Union Controlnet Pro workflow版本v1.0 (ID: 793440)

ComfyUI workflow for the Union Controlnet Pro from InstantX /Shakker Labs.
Available modes: Depth /Pose /Canny / Tile /Blur /Grayscale /Low quality

Instructions:

1. Update ComfyUI to the latest version

2. Download the model to models/controlnet

3. Load this workflow

4. Select the correct mode from the SetUnionControlNetType node (above the controlnet loader)

   Important: currently need to use this exact mapping to work with the new Union model:

   • canny - "openpose"

   • tile - "depth"

   • depth - "hed/pidi/scribble/ted"

   • blur - "canny/lineart/anime_lineart/mlsd"

   • pose - "normal"

   • gray - "segment"

   • low quality - "tile"

   So for example, to use the depth mode you would choose "hed/pidi/scribble/ted" in the SetUnionControlNetType node.

5. Adjust the strength and end_percent in the ControlNetApply node to find a suitable amount of influence. The sample values in the workflow (0.4 and 0.6) are quite gentle, you may want to increase them to have a stronger influence on the image. The model developer has given a recommended range of 0.3-0.8 for strength.

The archive also contains the openpose image used to generate the example image and the original photo the pose was extracted from.

Optional: if you want to extract input information from your own images, install the "ControlNet Auxiliary Preprocessors" custom node.
For openpose you can then enable the openpose extractor node (ctrl+b or right click -> Bypass).
Auxiliary preprocessors also include extractors for other modes such as depth and canny which you can put in place of the openpose image (remember to set the correct mode afterwards).
